FEATURES

Universal use in the nominal power class of 3.0 – 6.0 kW (Phaser 6) / 4.0 - 7.5 kW (Phaser 7),

this means ONE power supply drives different types of UV-lamps in the above named power class

Step less and quick adjustment of UV-lamp power, e.g. for step less adjustment of UV-power relative to the speed of a printing machine; or with interrupted process (e.g. quick power pulsing); or to adjust UV-power relative to lamp ageing.

To be placed in a cabinet or similar cooled housings, with max. temperature inside 40° C

Constant wattage UV-lamp output according to power settings

Not influenced by mains voltage fluctuation

Wide range of 3-phase mains voltages from 379 to 509 V, 50 and 60 Hz, including missing phase detection

Controlled by DC 0...10 V

Output is protected against ground faults, overload and short circuits, additionally open circuit

causes no problems

Easy to install and less wiring needed, no phase angle correction and no external ignitor needed

Lighter and in many cases smaller as a conventional power supply

In accordance to DIN VDE 0160 and other European and world wide standards (IEC)

CE sign, EMC according to EN 55011, group I, class A (industrial areas)

 TECHNICAL SPECIFICATIONS

Output Characteristics

 PHASER 6 / 450

 PHASER 7 / 450

Power range

 0.6 - 6.0 kW

 0.75 - 7.0 kW

Max. lamp voltage

 100 - 450 V

 100 - 450 V

Max. lamp current

 1.5 - 15 A

 1.8 - 18 A

Input Requirements

Power supply voltage

 376 - 509 V

 376 - 509 V

Power line current

 3 x 15 A (at 6.0 kW)

 3 x 17 A (at 7.5 kW)

Power line frequency

 50 - 60 Hz

 50 - 60 Hz

Electrical Properties

Electrical efficiency

 91 - 93%

 92 - 94%

Power factor

 0.70

 0.75

Power line loading

 Symmetrically on 3 Phases

 Symmetrically on 3 Phases

Connection

 L1, L2, L3, PE

 L1, L2, L3, PE

Ambient temperature

 0 - 40° C (32 to 104 F)

 0 - 40° C (32 to 104 F)

Physical Properties

Dimensions (LxWxH)

 400 x 125 x 270 mm

 400 x 125 x 270 mm

Weight

 14 kg

 15 kg
