FEATURES

Compact design, minimum space requirements, light weight. Easy Installation by one person only

No control cabinet required, little wiring effort, short circuit proof, short to earth proof

Compensation of mains voltage fl uctuations. Operates in industrial mains installations with standard

fault current breaker (FI)

Symmetrical power line loading on 3 phases

For UV-Lamps with power up to 12.0 kW, lamp current up to 30 A, lamp voltage up to 700 V

Operation of 1 - 3 standard lamps connected in series

Optimized ignition properties for all lamps

No dependence on lamp cable (type, shielding, length etc.)

Monitoring of operation and fault-state: 3 LEDs and a 7-segment display, as well as

PC-interface (digital output)

Selection and tuning of operation modes and parameters via PC-interface

Fast pulse operation: rise time < 2 ms

 TECHNICAL SPECIFICATIONS

Output Characteristics

Power range

 0.2 - 12.0 kW

Max. lamp voltage

 700 V

Max. lamp current

 30 A

Max. cable length to lamp

 20 m

Input Requirements

Power supply voltage

 376 - 509 V

Power line frequency

 48 - 62 Hz

Electrical Properties

Electrical efficiency

 ≥ 95%

Power factor

 > 0,80

Power line loading

 Symmetrically on 3 Phases

Lamp current shape

 Trapezoidal

Lamp ignition

 Integrated HF-Ignition

Conformity with standards

 IP54, EMV EN55011 degree A

Physical Properties

Dimensions (LxWxH)

 570 x 254 x 160 mm

Weight

 21 kg
